6/3/2022 Ampli Accuphase E-202
Type Stereo Integrated Amplifier Rated output (Both channel operation, 20Hz - 20kHz, THD 0.1%) 140W/ch(4 ohm) 100W/ch(8 ohm) 50W/ch(16 ohm) Total Harmonic Distortion (20Hz - 20kHz, High level input) 0.1%(Rated output) 0.05%(-3dB output) Intermodulation Distortion (High level input) 0.1%(Rated output, arbitrary frequency between 20Hz - 20kHz) Frequency Response(8 ohm, Rated input) Main amp input:20Hz - 20kHz +0 -0.2dB High level input:20Hz - 20kHz +0 -0.5dB Low level input:20Hz - 20kHz +0 -1.0dB Damping factor(8 ohm load,40Hz) Normal:50 Medium:5 Soft:1 Input Sensitivity/Impedance Main amp input:1.0V/100 kilohm High level input:160mV/100 kilohm DISC1 input:2.5mV - 5mV/30 kilohm、47 kilohm、100 kilohm DISC2 input:2.5mV/47 kilohm Maximum DISC input(THD 0.05%, 1kHz) DISC 1: 300 mVrms(Level control maximum) 600 mVrms(Level control minimum) DISC 2: 300 mVrms Rated output/Output Impedance Preamp output:1.0V/600 ohm Tape rec output:160mV/200 ohm Headphones:0.28V(Impedance:4 ohm - 32 ohm) Gain Main amp input - output:29dB High level input - Preamp output:16dB Low level input - Tape rec output:36dB S/N Main amp input:94dB(Rated input) High level input:80dB(Rated input) DISC input:74dB(10mV input) Volume control linkage error 1dB Tone control Turnover frequency Bass:400Hz Treble:2.5kHz Conversion range Bass:±10dB(100Hz) Treble:±10dB(10kHz) Compensator(Volume -30dB) +9dB(50Hz) DISC low enhancement +1dB(100Hz, to RIAA) Filter DISC Subsonic filter:25Hz, 6dB/oct Low filter:30Hz, 18dB/oct High filter:5kHz, 12dB/oct Power meter 100W(0dB, 8ohm load) Meter range switching: -10dB(10W = 0dB) -20dB(1W = 0dB) Used semiconductor Transistor:53 FET:4 Diode:44 Thermistor:2 Power supply voltage AC100V/117V/220V/240V, 50Hz/60Hz Power consumption 70W(No input) 375W(8ohm load, Rated output) Dimensions W455 x H152 x D355mm Weight 19.5kg Option Wood cabinet A-3
