Altium Designer Walkthrough, Schematic to PCB - Creating a Schematic (Part 1A)

A basic walkthrough of Altium Designer starting from Schematic to PCB. This series is intended for student and those new to Altium Designer. If you are working at a company, you may have different ways of handling your parts library. Useful references: Resistor Sizes and Packages https://eepower.com/resistor-guide/resistor-standards-and-codes/resistor-sizes-and-packages/ SMD IPC Footprint Dimensions http://livepartlibrary.com/fpdimensions.html How to calculate PTH hole and pad diameter sizes according to IPC https://www.pcb-3d.com/tutorials/how-to-calculate-pth-hole-and-pad-diameter-sizes-according-to-ipc-7251-ipc-2222-and-ipc-2221-standards/ Simple Design Rules (Seeed - Fusion PCB Specification) http://support.seeedstudio.com/knowledgebase/articles/447362-fusion-pcb-specification How to generate Gerber files in Altium Designer http://support.seeedstudio.com/knowledgebase/articles/1118680-how-to-generate-gerber-files-in-altium-designer
