ODROID H2 First Look - Benchmarks - Gameplay - Emulation
Its here! The all-new Odroid H2, So in this video, I’m gonna go over the specs pricing and performance using Windows 10. I run some Benchmarks test out some 4K video playback Steam “PC games and finally some emulators like Dolphin “Gamecube Wii” PPSSPP “PSP” And Dreamcast using Redream. Ameridroid: https://ameridroid.com/ Buy an H2: https://ameridroid.com/search?type=article%2Cpage%2Cproduct&q=h2* Amazon Links: Nvme SSD: https://amzn.to/2QiCUaS DDR4 Ram: https://amzn.to/2Qh9IRD WIFI: https://amzn.to/2QKk2ko Bluetooth Adapter: https://amzn.to/2QKjWt2 Bean Canyon NUC: https://amzn.to/2QhSymZ ?Twitter: https://twitter.com/theetaprime ? Become a Patron: https://www.patreon.com/ETAPRIME ? Support The Channel: Paypal - http://bit.ly/2gy2ffr ? Facebook Group: https://bit.ly/2rkuKPK Specifications Form Factor Dimensions: 110mm x 110mm x 47mm Weight: 285 g including heatsink Processor Intel Celeron J4105 Processor (14nm, TDP 10W) Up to 2.5Ghz(Single Thread) or 2.3Ghz(Multi Thread) 4MB L2 Cache UHD Graphics 600 (Gen 9.5 LP GT1 up to 700MHz) Fan-less design Memory 2 x DDR4 1.2V SO-DIMM slots Dual Channel, up to 2400 MT/s (DDR4-PC19200) Max memory capacity 32GB DDR3 is not supported Storage 1 x eMMC connector (bootable and selectable on BIOS) Various eMMC modules can be purchased at Hardkernel store 2 x SATA3 6Gbps 1 x M.2 NVMe slot (PCIe 2.0 x 4, supports NGFF-2280 cards) M.2 SATA SSD is not supported Networking 2 x GbE LAN ports (RJ45, supports 10/100/1000 Mbps) Realtek RTL8111G Supports Wake-On-Lan LED indicators (Green: Link, Amber: Traffic) Video 1 x DisplayPort 1.2 (up to 4K@60Hz) 1 x HDMI 2.0 (up to 4K@60Hz) Dual simultaneous display support Audio 1 x Audio out (3.5mm jack) 1 x Audio in (3.5mm jack) 1 x SPDIF out (ALC662, HDA codec) External I/O 2 x USB 3.0 Host ports 2 x USB 2.0 Host ports 1 x Peripheral Expansion Header (20-pin, 2.54mm pitch) 1 x DC 5V, 1 x DC 3.3V, 5 x GND 2 x UART (TXD/RXD/RTS/CTS) 2 x I2C (SCL/SDA) 1 x External Power Button All 3.3V I/O signal level Other features Passive Heatsink BIOS Backup Battery Maintains system time and BIOS settings Power Button Reset Button System LEDS Indicators: Red (PWR) – Solid light when DC power is supplied Blue (left, ALIVE) – Solid light when System is running Blue (right, RESET) – When the RESET button is pressed Amber (SATA) – Flashes when there is data transfer Green (NVMe) – Flashes when there is data transfer Active Cooling Fan Connector (5V 4-pin, PWM input + TACHO output) Active Cooling Fan is optional Connector (4-pin, 1.25mm pitch) Power 1 x DC jack : outer (negative) diameter 5.5mm, inner(positive) diameter 2.1mm DC 14V ~ 20V (up to 60W) DC 15V/4A power adaptor is recommended Power consumption: IDLE : ≃4W CPU Stress : ≃14W CPU+GPU Stress : ≃22W Power-off : ≃0.5W Suspend : ≃0.6W DISCLAIMER: This video and description contains affiliate links, which means that if you click on one of the product links, I’ll receive a small commission at no extra cost to you! THIS VIDEO IS FOR EDUCATIONAL PURPOSES ONLY! #odroid #SBC #ETAPRIME DISCLAIMER: Under section 107 of the Copyright Act 1976, allowance is made for “fair use” for purposes such as criticism, comment, news reporting, teaching, scholarship, education, and research. No Games Or Applications Are Included Or Added On Or To Any Device In This Video
